| Transmission lines/Substations |
Location |
Line length / Transformation capacity |
Specifications |
Contribution to total transmission charges |
| LILO of both circuits of Karcham Wangtoo – Abdullapur transmission line at Kala Amb
substation (on M/C towers) |
Himachal Pradesh |
2.47 ckm |
400 kV D/C |
84.50% |
| 400/220 kV GIS substation at Kala Amb |
Himachal Pradesh |
630 MVA |
400 kV / 220 kV GIS sub-station |
| 40% Series compensation on 400 kV Karcham Wangtoo – Kala Amb (Quad) D/C line at Kala Amb ends |
Himachal Pradesh |
- |
40% series compensation |
15.50% |
